Home > Products > Braided Rope
• Size: 3mm-38mm
• Structure: 8/16 strand
• Color: white or color
• Packing: coil/roll, spool, hank/bundle, reel
• Certificate: ISO, CE
• Hollow braided design allows fast and simple splicing
• Lightweight with high flexibility for easy handling
• Good abrasion, UV, and seawater resistance
• Stable structure with balanced load distribution
| Certification: | ISO CE |
The 8 / 16 Strand Hollow Braided Rope is produced from high-quality synthetic fibers with a hollow braided structure. This construction provides excellent flexibility, reduced weight, and easy splicing, making it ideal for a wide range of marine and industrial applications.
• Marine mooring, docking lines
• Towing and anchoring ropes
• Fishing and marine utility lines
• Industrial handling and general-purpose use
| SIZE | PP Braided Rope(ISO2307-2010) | Nylon Rope(ISO2307-2010) | Polyester Rope(ISO2307-2010) | |||
| Dia | Linear Density | MBL | Linear Density | MBL | Linear Density | MBL |
| (mm) | (g/m) | (kgs or tons) | (g/m) | (kgs or tons) | (g/m) | (kgs or tons) |
| 4 | 7.50 | 200kgf | 11.00 | 320kgf | 11.80 | 295kgf |
| 5 | 12.00 | 300 | 16.50 | 500 | 18.60 | 400 |
| 6 | 17.00 | 400 | 24.00 | 750 | 27.00 | 565 |
| 7 | 25.00 | 550 | 32.00 | 1,020 | 36.50 | 770 |
| 8 | 30.00 | 700 | 40.00 | 1,350 | 48.00 | 1,020 |
| 9 | 38.00 | 890 | 50.00 | 1,700 | 62.00 | 1,270 |
| 10 | 48.00 | 1,090 | 62.00 | 2,080 | 76.00 | 1,590 |
| 12 | 68.00 | 1,540 | 90.00 | 3,000 | 110.00 | 2,270 |
| 14 | 95.00 | 2,090 | 125.00 | 4,100 | 148.00 | 3,180 |
| 16 | 125.00 | 2.80Ts | 160.00 | 5.30Ts | 195.00 | 4.10Ts |
| 18 | 155.00 | 3.50 | 205.00 | 6.70 | 245.00 | 5.15 |
| 20 | 190.00 | 4.30 | 250.00 | 8.30 | 303.00 | 6.40 |
| 22 | 230.00 | 5.10 | 305.00 | 10.00 | 367.00 | 7.60 |
| 24 | 270.00 | 6.10 | 360.00 | 12.00 | 437.00 | 9.10 |
| 26 | 320.00 | 7.00 | 430.00 | 14.00 | 512.00 | 10.70 |
| 28 | 370.00 | 8.20 | 500.00 | 15.80 | 595.00 | 12.20 |
| 30 | 425.00 | 9.50 | 570.00 | 17.80 | 682.00 | 13.70 |
| 32 | 480.00 | 10.70 | 650.00 | 20.00 | 778.00 | 15.70 |
| 34 | 550.00 | 11.60 | 720.00 | 22.00 | 875.00 | 17.40 |
| 36 | 615.00 | 13.40 | 820.00 | 24.90 | 982.00 | 19.40 |
| 40 | 760.00 | 16.30 | 1000.00 | 30.00 | 1215.00 | 24.00 |
| 44 | 930.00 | 19.20 | 1200.00 | 35.80 | 1468.00 | 28.50 |
| 48 | 1100.00 | 22.80 | 1420.00 | 42.00 | 1750.00 | 33.60 |
| 52 | 1280.00 | 26.40 | 1650.00 | 48.90 | 2050.00 | 39.20 |
| 56 | 1490.00 | 30.40 | 1950.00 | 56.00 | 2380.00 | 44.80 |
| 60 | 1720.00 | 34.40 | 2230.00 | 63.90 | 2730.00 | 49.90 |
We are located in Linyi, a beautiful and livable city, That is a major logistics hub in China. With over 15 years of experience, We provide premium grade UHMWPE ropes, Anti snap back ropes, Mixed ropes, PP ropes, PE ropes and twine for marine, Fishing and agriculture.
