UHMPE Rope Plus

• Size: 40mm-96mm

• Length: 100m, 220m or customized

• Material: UHMWPE rope core with polyester jacket

• Color: orange, yellow, grey or customized

• Certificate: BV, CCS, DNV, ABS, etc.

• High Strength with Low Weight

• Low Elongation under Load

• Excellent Abrasion & Fatigue Resistance

• Corrosion-Free & Zero Water Absorption

• Enhanced Operational Safety

Product Parameters

Certification:

BV, DNV, CCS, ABS, ISO, CE

Description

HMPE mooring rope Plus is a rope made of UHMWPE rope core with polyester jacket. This kind of rope has the advantage of UHMWPE rope and polyester rope.

Applications

Mooring, marine, anchor, towing.

Specifications

Size		Weight		MBL(Unspliced)		LDBF(Spliced)
Dia.mm	Cir.inch	g/m	kgs/220m	kN	ton	kN	ton
40	5	940	206.8	1140	116.3	1030	105.1
44	5-1/2	1150	253.0	1380	140.8	1240	126.5
48	6	1360	299.2	1610	164.3	1450	148.0
52	6-1/2	1600	352.0	1920	195.9	1730	176.5
56	7	1850	407.0	2190	223.5	1970	201.0
60	7-1/2	2120	466.4	2520	257.1	2270	231.6
64	8	2400	528.0	2880	293.9	2590	264.3
68	8-1/2	2720	598.4	3260	332.7	2930	299.0
72	9	3070	675.4	3630	370.4	3270	333.7
76	9-1/2	3400	748.0	4020	410.2	3620	369.4
80	10	3750	825.0	4510	460.2	4060	414.3
84	10-1/2	4125	907.5	4930	503.1	4440	453.1
88	11	4500	990.0	5350	545.9	4820	491.8
92	11-1/2	4900	1078.0	5815	593.4	5235	534.2
96	12	5300	1166.0	6280	640.8	5650	576.5
