• Size: 24mm-120mm
• Length: 100m, 220m or customized
• Material: polypropylene monofilament fiber & polyester fiber
• Color: white or color
• Certificate: BV, CCS, DNV, ABS, etc.
• Density: <1.0 floating
• Melting point: 165℃/260℃
• Elongation: 12%-17%
• Abrasion resistance: excellent
• UV resistance: good
• Chemical resistance: good
| Certification: | BV, DNV, CCS, LR, KR, ABS |
Ratio of polypropylene and polyester in the composite rope
In the mixed mooring rope, we can adjust the ratio of polypropylene and polyester fibers according to your requirements. We usually produce 30% polyester fiber and 70% polypropylene. The density of this ratio is below 1.0. So the rope can float on the water surface. Meanwhile, ropes with this ratio will gain the advantages of polyester ropes and optimize their circumference. Due to the superiority of polyester materials, mixed ropes will have higher strength and stronger UV resistance than ordinary PP ropes. Meanwhile, the higher the proportion of polypropylene fibers, the lighter the rope and can float on the water surface.
If you hope to gain different performance of rope, you can adjust the ratio of polypropylene and polyester. For example 25% polyester plus 75% polypropylene will have lighter weight of rope and less breaking strength than the rope with 30% polyester fiber.
50% polypropylene plus 50%polyester will get higher strength and heavier rope. It will help you solve special problem the polyester rope can not.
The composite rope is used for ship, ocean transportation, port towing, oil tankers, chemical tankers, large bulk carries, offshore fishing and other fields.
| Size | Weight | MBL(Unsplice) | LDBF(Spliced) | ||||
| Dia.mm | Cir.inch | g/m | kgs/220m | kN | ton | kN | ton |
| 24 | 3 | 335 | 74 | 123 | 12.5 | 110 | 11.3 |
| 28 | 3-1/2 | 460 | 101 | 163 | 16.6 | 147 | 15 |
| 32 | 4 | 595 | 131 | 209 | 21.3 | 188 | 19.2 |
| 36 | 4-1/2 | 742 | 163 | 273 | 27.8 | 245 | 25 |
| 40 | 5 | 915 | 201 | 330 | 33.6 | 297 | 30.3 |
| 44 | 5-1/2 | 1090 | 240 | 392 | 40 | 353 | 36 |
| 48 | 6 | 1320 | 290 | 453 | 46.2 | 408 | 41.6 |
| 50 | 6-1/4 | 1410 | 310 | 490 | 49.9 | 441 | 45 |
| 52 | 6-1/2 | 1500 | 330 | 526 | 53.6 | 473 | 48.3 |
| 56 | 7 | 1790 | 394 | 608 | 62 | 547 | 55.9 |
| 60 | 7-1/2 | 2005 | 441 | 692 | 70.5 | 622 | 63.5 |
| 64 | 8 | 2260 | 497 | 775 | 79.1 | 698 | 71.2 |
| 68 | 8-1/2 | 2540 | 559 | 868 | 88.6 | 781 | 79.7 |
| 70 | 8-3/4 | 2690 | 592 | 920 | 93.8 | 828 | 84.5 |
| 72 | 9 | 2840 | 625 | 971 | 99.1 | 874 | 89.2 |
| 75 | 9-3/8 | 3080 | 678 | 1048 | 106.9 | 944 | 96.3 |
| 80 | 10 | 3490 | 768 | 1177 | 120.1 | 1059 | 108.1 |
| 85 | 10-5/8 | 3933 | 865 | 1330 | 135.7 | 1197 | 122.2 |
| 88 | 11 | 4200 | 924 | 1422 | 145.1 | 1280 | 130.6 |
| 90 | 11-1/4 | 4400 | 968 | 1489 | 151.8 | 1340 | 136.7 |
| 95 | 11-7/8 | 4900 | 1078 | 1654 | 168.7 | 1489 | 151.9 |
| 96 | 12 | 5000 | 1100 | 1687 | 172.1 | 1519 | 155 |
| 100 | 12-1/2 | 5430 | 1195 | 1834 | 187.1 | 1651 | 168.5 |
| 104 | 13 | 5860 | 1289 | 1982 | 202.1 | 1783 | 182 |
| 112 | 14 | 6740 | 1483 | 2286 | 233.1 | 2057 | 209.9 |
| 120 | 15 | 7740 | 1703 | 2609 | 266.2 | 2348 | 239.6 |
